SunGard® SG
SunGard® SG
General Description
SunGard® SG is a weatherable polycarbonate sheet that combines the impact strength of polycarbonate with outstanding ultra-violet (UV) stability. SunGard® SG's unique properties make it the perfect choice for a variety of exterior sign applications. Both SunGard® products are UL listed as UL746 F1 Suitable for Outdoor Use. SunGard® SG is UL94 HB yellow card listed for white and clear products.
Technical
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Specific Gravity | ASTM D-792 | 1.2 | n/a |
| Melt flow rate (300C/1.2kg) | ASTM D-1238 | 6.0 | g/10 min |
| Tensile Strength | ASTM D-638 | 9,000 | psi |
| Tensile Elongation @ Yield | ASTM D-638 | 6.00 | % |
| Tensile Elongation at Break | ASTM D-638 | 120 | % |
| Flex Strength | ASTM D-790 | 13,000 | psi |
| Flex Modulus | ASTM D-790 | 335,000 | psi |
| Notched Izod at 73°F | D-256 | 17 | ft-lb/in |
| Rockwell Hardness (R Scale) | ASTM D-785 | 110 | n/a |
| Heat Deflection Temperature @264 psi | ASTM D-648 | 260 | °F |
| Vicat Softening Temperature | ASTM D-1525 | 291 | °F |
| CLTE | ASTM E-831 | 3.8 | E-5 in/in/F |
| Flammability | UL94-V / UL94l-HB | Listed: UL94-HB | @ 0.098" |
| Light Transmittance (100mil) | ASTM D-1003 | 88 to 90 | % |
| Haze (100mil) | ASTM D-1003 | < 1 | % |
Performance
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Chemical Resistance | n/a | High | n/a |
| Flexural Modulus (stiffness) | n/a | High | n/a |
| Formability | n/a | Good | n/a |
| Gloss After Forming | n/a | High | n/a |
| Hardness | n/a | Very Good | n/a |
| Heat Deflection Temperature | n/a | Very High | n/a |
| Impact Strength | n/a | Very High | n/a |
| Low Temperature Impact Strength | n/a | Average | n/a |
| Tensile Strength | n/a | High | n/a |
| UV Resistance | n/a | h | n/a |
Product Information
| Item | Description |
|---|---|
| Product Line | SunGard® |
| Item Code | SunGard® SG |
| Material Description | Polycarbonate |
| Product Description | Weatherable Polycarbonate Sheet |
| Characteristics |
|
Polymers
| Polymer Tag | Polymer Name |
|---|---|
| PC | Polycarbonate |
Related Documents
| Title | Open |
|---|---|
| TDS—SunGard® | Open |
| AIS—SunGard® SG Clear | Open |
| AIS—SunGard® SG White | Open |
| AIS—SunGard® SG | Open |
| Sign Materials Guide - Sungard® SG, Crylex®, Tuf-Glas®, WeatherPro™ SG | Open |
*All values based on 0.125" unless otherwise stated
