Royalite® R63

Royalite® R63

General Description

Royalite® R63 thermoplastic sheet is an PVC/ABS product that is both electrically conductive and fire-rated. It meets the minimum static decay requirements outlined in MIL-B-81705C and NFPA Code 99 specifications. It is recognized under the component program of Underwriters Laboratories, Inc. with a classification of 94V-1 at 0.066”. Containers made from Royalite® R63 thermoplastic sheet provide permanent static protection. It provides the dimensional stability typical of ABS plastics required for today’s robotic material handling systems. Royalite® R63 thermoplastic sheet combines high stiffness and abrasion resistance with excellent thermoformability.

Technical

Properties Test Method Value UOM
Specific Gravity ASTM D-792 1.22 n/a
Tensile Strength ASTM D-638 4,500 psi
Flexural Strength ASTM D-790 7,100 psi
Flexural Modulus ASTM D-790 280,000 psi
Rockwell Hardness (R Scale) ASTM D-785 87 n/a
Heat Deflection Temperature @264 psi, Annealed ASTM D-648 165 °F
Falling Dart Impact -40°C ASTM D-5420 160 ft lbs
Surface Resistivity ASTM D-257 < 10^5 Ω Ohm2

Performance

Properties Test Method Value UOM
Chemical Resistancen/an/a
Flexural Modulus (stiffness)n/aHighn/a
Formabilityn/aGoodn/a
Gloss After Formingn/an/a
Hardnessn/an/a
Heat Deflection Temperaturen/aAveragen/a
Impact Strengthn/aHighn/a
Low Temperature Impact Strengthn/aAveragen/a
Tensile Strengthn/aHighn/a
UV Resistancen/aGoodn/a
Spartech Royalite® R63

Product Information

Item Description
Product Line Royalite®
Item Code Royalite® R63
Material Description Conductive, fire-rated PVC/ABS rigid sheet
Product Description Fire-Rated, Electrically-Conductive Sheet
Characteristics
  • Meets: Static Decay MIL-B-81705C
  • Meets: NFPA Code 99
  • Listed: UL 94 V-1 @ > 0.066"
  • Surface resistivity < 10^5 Ω
BenefitsRoyalite® Electrostatic Dissipative (ESD) thermoplastic sheet meets permanent static protection requirements and these products meet minimum static decay requirements outlined in MIL-B-81705C and NFPA Code 99 specifications.
Applications
  • Dissipation of electrostatic charges
  • IC chip carriers
  • Trays and tray dividers

*All values based on 0.125" unless otherwise stated

Customers are responsible for determining whether products and information are appropriate for their use, including the evaluation of all applicable laws. Spartech LLC assumes no liability for the accuracy or completeness of information contained herein, and such information is subject to change without notice. All products supplied are subject to the standard terms and conditions of sale of Spartech LLC. NO WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, IS MADE BY THIS TECHNICAL DATA SHEET. ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED.
