Royalite® R59
Royalite® R59
General Description
Royalite® R59 thermoplastic sheet provides a unique PVC/ABS product that meets many industry flammability standards. It is recognized under the component program of Underwriters Laboratories, Inc. with a classification of 94V-1 at 0.058", 94V-0 at 0.085" and 94-5VA at 0.085". It combines very high impact strength with excellent ductility and formability.
Technical
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Specific Gravity (color dependent) | ASTM D-792 | 1.18 - 1.25 | n/a |
| Tensile Strength | ASTM D-638 | 5,000 | psi |
| Flexural Strength | ASTM D-790 | 7,800 | psi |
| Flexural Modulus | ASTM D-790 | 280,000 | psi |
| Izod Impact (Notched) 72°F | ASTM D-256 | 8 | ft-lbs/in |
| Izod Impact (Notched) -40°C | ASTM D-256 | 1.8 | ft-lbs/in |
| Rockwell Hardness (R Scale) | ASTM D-785 | 93 | n/a |
| Heat Deflection Temperature @264 psi, Annealed | ASTM D-648 | 175 | °F |
| Coefficient of Linear Thermal Expansion | ASTM D-696 | 4.6 - 5.5 | x10-5 in/in/°F |
| Mold Shrinkage | Internal | 0.005 - 0.007 | in/in |
| Motor Vehicle Safety Standard | FMVSS 302 | Passes | n/a |
| Flammability | UL 94 V-0 | Listed @ 0.085" | n/a |
| Flammability | UL 94-5VA | Listed @ 0.085" | n/a |
| Radiant Panel (Flame Spread Index) | UL 94 | RP50 | n/a |
| Relative Thermal Index (Electrical), ≥ 0.086” | UL 746 | 85 | °C |
| Relative Thermal Index (Mech. w/impact), ≥ 0.086” | UL 746 | 70 | °C |
| Relative Thermal Index (Mech. w/o impact), ≥ 0.086” | UL 746 | 85 | °C |
| Ball Pressure Test (72°C, 3.00 mm) | IEC 60695-10-2 | Passes | n/a |
Performance
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Chemical Resistance | n/a | n/a | |
| Flexural Modulus (stiffness) | n/a | High | n/a |
| Formability | n/a | Very Good | n/a |
| Gloss After Forming | n/a | n/a | |
| Hardness | n/a | High | n/a |
| Heat Deflection Temperature | n/a | Average | n/a |
| Impact Strength | n/a | Very High | n/a |
| Low Temperature Impact Strength | n/a | High | n/a |
| Tensile Strength | n/a | High | n/a |
| UV Resistance | n/a | Low | n/a |
Product Information
| Item | Description |
|---|---|
| Product Line | Royalite® |
| Item Code | Royalite® R59 |
| Material Description | PVC/ABS |
| Product Description | Fire-rated PVC/ABS rigid sheet |
| Characteristics |
|
| Applications |
|
Polymers
| Polymer Tag | Polymer Name |
|---|---|
| RPVC | Rigid Polyvinyl Chloride |
| Alloy | Thermoplastic Alloy |
Related Documents
| Title | Open |
|---|---|
| Royalite® Product Line Bulletin | Open |
| AIS—Royalite® R559 W R59 | Open |
| AIS—Royalite® R59 W R59 | Open |
| AIS—Royalite® R59 | Open |
*All values based on 0.125" unless otherwise stated
